NNT Electronic Air Pressure Switch -50kpa-0.75mpa with Separate monitor
Product Details:
| Place of Origin: | China |
| Brand Name: | NNT |
| Certification: | CE |
| Model Number: | NPF2A7 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 piece |
|---|---|
| Price: | US＄95 |
| Packaging Details: | carton box |
| Delivery Time: | 7 days |
| Payment Terms: | L/C, D/A, D/P, T/T |
| Supply Ability: | 10000/pieces per month |
|
Detail Information |
|||
| Minimum Set Unit: | 0.1~5(l/min) | Flow Rate Measurement Range: | 1~500(l/min) |
|---|---|---|---|
| Pressure Range: | -50KPa~0.75MPa | Type: | Separate Monitor |
| Output: | Switch Output, Accumulated Pulse Output, Analog Output | ||
| Highlight: | 0.75mpa Electronic Air Pressure Switch,-50kpa Electronic Air Pressure Switch,NNT electronic air pressure sensor |
||
Product Description
NNT Electronic Pressure Switch -50kpa-0.75mpa Digital Air Flow Meters
The principle of thermal diffusion flow switch. Thermal diffusion technology is a technology with excellent performance and high reliability under harsh conditions. Its typical principle is that when two sensing elements are placed in a fluid, one of them is heated and the other is used. For sensing process temperature. The temperature difference between the two sensing elements is related to the process flow rate and the nature of the process medium. The temperature difference between the two sensing elements is the largest in the no-flow state, but as the flow increases, the heated sensing element is cooled and the temperature difference decreases. The fluid velocity directly affects the degree of thermal diffusion.
| Model | NPF2A710-01-27 | NPF2A750-02-27 | NPF2A711-03-27 | NPF2A721-03-27 | NPF2A751-04-27 |
| Port Size | 1/8 | 1/4 | 3/8 | 3/8 | 1/2 |
| Measured Fluid | Air,N2 | Air,N2 | Air,N2 | Air,N2 | Air,N2 |
| Rated Flow Range | 1~10 | 5~50 | 10~100 | 20~200 | 50~500 |
| Minimum Unit Set | 0.1 | 0.5 | 1 | 2 | 5 |
